Volume pricing
- 1+ pcs$0.91
- 10+ pcs$0.86
- 100+ pcs$0.81
- 500+ pcs$0.77
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Sıra Sayısı
- 1
- Pozisyon Sayısı
- 3
- Contact Type
- Male Pin
- Terminal Adımı
- 2.54mm
- Contact Materials
- Phosphor Bronze
- Çalışma Sıcaklığı
- -40°C~105°C
- Montaj Tipi
- Through Hole
- Contact Finish Thickness Post
- 74.8μin 1.90μm
- RoHS Durumu
- ROHS3 Compliant
- Overall Contact Length
- 0.470 11.94mm
- Terminal
- Solder
- Rated Current Signal
- 3A
- Contact Finish Thickness Mating
- 15.0μin 0.38μm
- Nominal Gerilim
- 250V
- Ambalaj
- Tube
- Number Of Positions Loaded
- All
- JESD-609 Kodu
- e3
- Parça Durumu
- Active
- Mixed Contacts
- NO
- Pcb Contact Pattern
- RECTANGULAR
- Fabrika Tedarik Süresi
- 5 Weeks
- Applications
- Automotive, General Purpose, Industrial, Medical
- Connector Type
- Header
- Insulation Materials
- Polyester, Glass Filled
- Pitch Mating
- 0.100 2.54mm
- Number Of Pcb Rows
- 1
- Filter Feature
- NO
- Contact Shape
- Square
- Reference Standard
- CSA, UL
- Contact Lengthmating
- 0.240 6.10mm
- Contact Finish Mating
- Gold
- Style
- Board to Cable/Wire
- Number Of Conductors
- ONE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Length Post
- 0.130 3.30mm
- Seri
- SL 70543
- Shrouding
- Shrouded - 4 Wall
- Ul Flammability Code
- 94V-0
- Contact Finish Post
- Tin
- Additional Feature
- SL
