Volume pricing
- 1+ pcs$5.85
- 10+ pcs$5.52
- 100+ pcs$5.20
- 500+ pcs$4.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Applications
- Automotive, General Purpose, Lighting, Medical, Telecommunications
- Contact Type
- Male Pin
- Ambalaj
- Bulk
- Contact Lengthmating
- 0.240 6.10mm
- Terminal
- Solder
- Pitch
- 2.54mm
- Fastening Type
- Push-Pull
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz
- Lead Free
- Akım Değeri
- 3A
- Contact Plating
- Tin
- Contact Materials
- Copper Alloy
- Orientation
- Vertical
- Contact Finish Thickness Mating
- 150.0μin 3.81μm
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Through Hole
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Shape
- Square
- Shrouding
- Unshrouded
- Insulation Materials
- Liquid Crystal Polymer (LCP), Glass Filled
- Insulation Height
- 0.090 2.29mm
- Row Spacing Mating
- 0.100 (2.54mm)
- Montaj
- Through Hole
- Contact Finish Post
- Tin
- Style
- Board to Board or Cable
- Parça Durumu
- Active
- Number Of Circuits
- 88
- Contact Length Post
- 0.107 2.71mm
- Insulation Color
- Black
- Pozisyon Sayısı
- 90
- Overall Contact Length
- 0.437 11.10mm
- Pitch Mating
- 0.100 2.54mm
- Number Of Positions Loaded
- All
- Housing Color
- Black
- Sıra Sayısı
- 2
- Renk
- Black
- Seri
- C-Grid 70280
- Connector Type
- Header, Breakaway
- Contact Finish Mating
- Tin
