Specifications
- Seri
- MicroTPA 55487
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Length Post
- 0.130 3.30mm
- Contact Finish Mating
- Tin
- Montaj Tipi
- Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Insulation Height
- 0.520 13.20mm
- Montaj
- Through Hole
- Applications
- Automotive, General Purpose, Industrial
- Sıra Sayısı
- 1
- Contact Shape
- Square
- Pozisyon Sayısı
- 12
- Reach Svhc
- No SVHC
- Glow Wire Compliant
- Non-compliant
- Ambalaj
- Tray
- Overall Contact Length
- 0.604 15.35mm
- Özellikler
- Board Guide
- Orientation
- Vertical
- Material Flammability Rating
- UL94 V-0
- Akım Değeri
- 2.5A
- Shrouding
- Shrouded - 4 Wall
- Insulation Color
- White
- Contact Finish Post
- Tin
- Connector Type
- Header
- Min. Çalışma Sıcaklığı
- -25°C
- Style
- Board to Cable/Wire
- Number Of Contacts
- 12
- Gender
- Male
- Contact Materials
- Brass
- Nominal Gerilim
- 250V
- Terminal
- Kinked Pin, Solder
- Housing Material
- Nylon
- Insulation Materials
- Polyamide (PA66), Nylon 6/6, Glass Filled
- Contact Plating
- Tin
- Parça Durumu
- Active
- Fastening Type
- Latch Lock
- Contact Type
- Male Pin
- Number Of Positions Loaded
- All
- Maks. Çalışma Sıcaklığı
- 85°C
- Stack Height Mating
- 17.7mm
