Specifications
- Sıra Sayısı
- 2
- Kurşunsuz Kodu
- yes
- Pozisyon Sayısı
- 24
- Contact Shape
- Square
- Contact Type
- Female Socket
- Terminal Adımı
- 3mm
- Iec Conformance
- NO
- Mixed Contacts
- NO
- Contact Finish Post
- Tin
- JESD-609 Kodu
- e3
- Montaj Tipi
- Through Hole, Right Angle
- Çalışma Sıcaklığı
- -40°C~105°C
- Material Flammability Rating
- UL94 V-0
- Din Conformance
- NO
- RoHS Durumu
- ROHS3 Compliant
- Connector Type
- Receptacle
- Insulation Color
- Black
- Fastening Type
- Push-Pull
- Ul Flammability Code
- 94V-0
- Insulation Height
- 0.402 10.20mm
- Fabrika Tedarik Süresi
- 12 Weeks
- Contact Length Post
- 0.155 3.94mm
- Style
- Board to Board or Cable
- Terminal
- Solder
- Filter Feature
- NO
- Mil Conformance
- NO
- Pitch Mating
- 0.118 3.00mm
- Seri
- Micro-Fit 3.0 BMI 44764
- Contact Finish Mating
- Gold
- Ambalaj
- Tray
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Current Rating Amps
- 5A
- Özellikler
- Board Guide
- Number Of Positions Loaded
- All
- Contact Materials
- Phosphor Bronze
- Row Spacing Mating
- 0.118 (3.00mm)
- Contact Finish Thickness Post
- 100.0μin 2.54μm
- Insulation Materials
- Liquid Crystal Polymer (LCP), Glass Filled
- Parça Durumu
- Active
