Specifications
- Nominal Gerilim
- 600V
- Mil Conformance
- NO
- Filter Feature
- NO
- Material Flammability Rating
- UL94 V-0
- Fastening Type
- Locking Ramp
- Montaj Tipi
- Through Hole
- Özellikler
- Board Guide
- Contact Materials
- Brass
- Style
- Board to Cable/Wire
- Contact Type
- Male Pin
- Contact Shape
- Square
- Din Conformance
- NO
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Shrouding
- Shrouded - 4 Wall
- Additional Feature
- MICRO-FIT 3.0, POLARIZED, SHROUDED
- Ambalaj
- Tray
- Contact Finish Post
- Tin
- Insulation Materials
- Liquid Crystal Polymer (LCP), Glass Filled
- Pitch Mating
- 0.118 3.00mm
- Shell Material
- POLYETHYLENE
- Seri
- Micro-Fit 3.0 43045
- Ul Flammability Code
- 94V-0
- Iec Conformance
- NO
- Terminal
- Kinked Pin, Solder
- Sıra Sayısı
- 2
- Row Spacing Mating
- 0.118 (3.00mm)
- Number Of Positions Loaded
- All
- Empty Shell
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Length Post
- 0.125 3.18mm
- Insulation Color
- Black
- Contact Finish Thickness Post
- 100.0μin 2.54μm
- Applications
- General Purpose, Medical, Military, Telecommunications
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Insulation Height
- 0.390 9.91mm
- Contact Finish Mating
- Gold
- Current Rating Amps
- 8A
- Pozisyon Sayısı
- 22
- HTS Kodu
- 8536.69.40.30
