Specifications
- Row Spacing Mating
- 0.165 (4.20mm)
- Insulation Height
- 0.504 12.80mm
- Style
- Board to Cable/Wire
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 6 Weeks
- Pozisyon Sayısı
- 18
- Insulation Color
- Natural
- Contact Length Post
- 0.138 3.50mm
- Pitch Mating
- 0.165 4.20mm
- Number Of Positions Loaded
- All
- Contact Finish Thickness Post
- 35.0μin 0.90μm
- Sıra Sayısı
- 2
- Seri
- Mini-Fit Jr 5566
- Connector Type
- Header
- Contact Finish Mating
- Tin
- Applications
- General Purpose, Industrial, Telecommunications
- Ambalaj
- Tray
- Contact Type
- Male Pin
- Terminal
- Solder
- Fastening Type
- Locking Ramp
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- Brass
- Özellikler
- Board Lock
- Contact Finish Thickness Mating
- 35.4μin 0.90μm
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Through Hole
- Shrouding
- Shrouded - 4 Wall
- Contact Shape
- Square
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Materials
- Polyamide (PA66), Nylon 6/6
