Specifications
- Kurşunsuz Kodu
- yes
- JESD-609 Kodu
- e3
- Contact Type
- Male Pin
- Contact Shape
- Square
- Terminal Adımı
- 2.54mm
- Mixed Contacts
- NO
- Montaj Tipi
- Through Hole, Right Angle
- Connector Type
- Header
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Shrouding
- Unshrouded
- Fabrika Tedarik Süresi
- 10 Weeks
- Insulation Materials
- Polyamide (PA), Nylon
- Applications
- Automotive, General Purpose, Medical, Telecommunications
- Fastening Type
- Push-Pull
- Number Of Positions Loaded
- All
- Material Flammability Rating
- UL94 V-0
- Contact Finish Thickness Mating
- 60.0μin 1.52μm
- Contact Lengthmating
- 0.369 9.37mm
- Iec Conformance
- NO
- Mil Conformance
- NO
- Contact Length Post
- 0.124 3.15mm
- Sıra Sayısı
- 1
- Insulation Color
- White
- Seri
- KK 4094
- Style
- Board to Board or Cable
- Filter Feature
- NO
- Pozisyon Sayısı
- 9
- Contact Finish Mating
- Tin
- RoHS Durumu
- ROHS3 Compliant
- Din Conformance
- NO
- Insulation Height
- 0.130 3.30mm
- Terminal
- Solder
- Contact Finish Thickness Post
- 60.0μin 1.52μm
- Contact Materials
- BRASS
- Pitch Mating
- 0.100 2.54mm
- Ambalaj
- Bulk
- Parça Durumu
- Active
