Specifications
- Gateemitter Voltagemax
- 20V
- Montaj Tipi
- Chassis Mount
- Genişlik
- 40.8mm
- Kurşunsuz
- Lead Free
- Qualification Status
- Not Qualified
- Terminal Pozisyonu
- UPPER
- Max Collector Current
- 100A
- Turn Off Timenom Toff
- 310 ns
- RoHS Durumu
- RoHS Compliant
- Turn On Time
- 170 ns
- Polaritychannel Type
- N-CHANNEL
- Uzunluk
- 51.6mm
- Kurşunsuz Kodu
- yes
- Collector Emitter Voltage Vceo
- 600V
- Tedarikçi Cihaz Paketi
- SP1
- Configuration
- Half Bridge
- Collectoremitter Breakdown Voltage
- 600V
- Lifecycle Status
- IN PRODUCTION (Last Updated: 3 weeks ago)
- Kılıf / Paket
- SP1
- Input Capacitance Cies Vce
- 4.62nF @ 25V
- Transistor Element Material
- SILICON
- Vcesatmax
- 1.9 V
- Terminal Formu
- THROUGH-HOLE
- Input Capacitance
- 4.62nF
- Current Collector Cutoff Max
- 250μA
- Transistor Application
- MOTOR CONTROL
- Igbt Type
- Trench Field Stop
- Pin Sayısı
- 12
- Yayın Yılı
- 2007
- Ürün Durumu
- Active
- Parça Durumu
- Active
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Paket
- Bulk
- Collectoremitter Saturation Voltage
- 1.5V
- Continuous Collector Current
- 100
- Ntc Thermistor
- Yes
- Input
- Standard
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Montaj
- Chassis Mount, Screw
- Terminal Kaplaması
- TIN SILVER COPPER
