Specifications
- Max Collector Current
- 700A
- Turn Off Timenom Toff
- 400 ns
- Terminal Pozisyonu
- UPPER
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Chassis Mount
- Pd Power Dissipation
- 2.3 kW
- Polaritychannel Type
- N-CHANNEL
- RoHS Durumu
- RoHS Compliant
- Turn On Time
- 205 ns
- Kurşunsuz Kodu
- yes
- Collector Emitter Voltage Vceo
- 600V
- Maks. Çalışma Sıcaklığı
- 175 °C
- Configuration
- Single
- Power Dissipation
- 2.3
- Tedarikçi Cihaz Paketi
- SP6
- Maximum Gate Emitter Voltage
- 20 V
- Input Capacitance Cies Vce
- 49nF @ 25V
- Transistor Element Material
- SILICON
- Kılıf / Paket
- SP6
- Lifecycle Status
- IN PRODUCTION (Last Updated: 3 weeks ago)
- Collectoremitter Breakdown Voltage
- 600V
- Current Collector Cutoff Max
- 750μA
- Input Capacitance
- 49nF
- Terminal Formu
- UNSPECIFIED
- Parça Durumu
- Active
- Ürün Durumu
- Active
- Yayın Yılı
- 2006
- Transistor Application
- POWER CONTROL
- Igbt Type
- Trench Field Stop
- Additional Feature
- AVALANCHE RATED
- Pin Sayısı
- 5
- Min. Çalışma Sıcaklığı
- -40 °C
- Paket
- Bulk
- Ambalaj
- Tube
- Continuous Collector Current At25 C
- 700 A
- Continuous Collector Current
- 700
- Birim Ağırlık
- 3.880136 oz
- Collectoremitter Saturation Voltage
- 1.4 V
- Minimum Operating Temperature
- - 40 C
- Collector Emitter Voltage Vceo Max
- 600 V
