APTGT50H120T3G

Specifications

Montaj Stili

Chassis Mount

Gateemitter Leakage Current

400 nA

Terminal Sayısı

25

Terminal Kaplaması

TIN SILVER COPPER

Currentcollector Ic Max

75 A

Number Of Elements

4

Case Connection

ISOLATED

Ntc Thermistor

Yes

Input

Standard

RoHS

Details

Montaj

Chassis Mount, Screw

Collector Emitter Voltage Vceo Max

1.2 kV

Minimum Operating Temperature

- 40 C

Collectoremitter Saturation Voltage

1.7 V

Continuous Collector Current

75

Continuous Collector Current At25 C

75 A

Max Power Dissipation

270W

Fabrika Paket Adedi

1

Power Max

270W

Pin Sayısı

3

Voltage Collector Emitter Breakdown Max

1200V

Maks. Çalışma Sıcaklığı

+ 100 C

ECCN Kodu

EAR99

Fabrika Tedarik Süresi

36 Weeks

Nem Hassasiyeti (MSL)

1 (Unlimited)

Çalışma Sıcaklığı

-40°C~150°C TJ

JESD-609 Kodu

e1

Temel Ürün No

APTGT50

Vceon Max Vge Ic

2.1V @ 15V, 50A

Tedarikçi Cihaz Paketi

SP3

Power Dissipation

270

Configuration

Full Bridge Inverter

Kurşunsuz Kodu

yes

Collector Emitter Voltage Vceo

2.1V

RoHS Durumu

RoHS Compliant

Turn On Time

140 ns

Pd Power Dissipation

270 W

Polaritychannel Type

N-CHANNEL

Montaj Tipi

Chassis Mount

Terminal Pozisyonu

UPPER
