Specifications
- Min. Çalışma Sıcaklığı
- -40 °C
- Radyasyon Dayanımı
- No
- Paket
- Bulk
- Üretici Parça No
- 78101105440
- Ürün Durumu
- Active
- Parça Durumu
- Active
- Yayın Yılı
- 2006
- Igbt Type
- Trench Field Stop
- Additional Feature
- AVALANCHE RATED
- Pin Sayısı
- 14
- Transistor Application
- POWER CONTROL
- Current Collector Cutoff Max
- 250μA
- Input Capacitance
- 3.6nF
- Terminal Formu
- UNSPECIFIED
- Transistor Element Material
- SILICON
- Input Capacitance Cies Vce
- 3.6nF @ 25V
- Lifecycle Status
- Production (Last Updated: 2 months ago)
- Kılıf / Paket
- SP4
- Collectoremitter Breakdown Voltage
- 1.2kV
- Configuration
- Asymmetrical Bridge
- Tedarikçi Cihaz Paketi
- SP4
- Collector Emitter Voltage Vceo
- 1.2kV
- Kurşunsuz Kodu
- yes
- Maks. Çalışma Sıcaklığı
- 150 °C
- Polaritychannel Type
- N-CHANNEL
- Pd Power Dissipation
- 277 W
- Turn On Time
- 140 ns
- RoHS Durumu
- RoHS Compliant
- Jesd30 Code
- R-XUFM-X14
- Turn Off Timenom Toff
- 610 ns
- Max Collector Current
- 75A
- Terminal Pozisyonu
- UPPER
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Chassis Mount
- Turn Off Delay Time
- 420 ns
- ECCN Kodu
- EAR99
- Maks. Çalışma Sıcaklığı
- + 100 C
- Pin Sayısı
- 20
- Voltage Collector Emitter Breakdown Max
- 1200V
- Power Max
- 277W
