Specifications
- Pin Sayısı
- 20
- Maks. Çalışma Sıcaklığı
- 175 °C
- RoHS
- Details
- Turn On Time
- 180 ns
- Element Configuration
- Dual
- Igbt Type
- Trench Field Stop
- Collectoremitter Breakdown Voltage
- 600V
- Case Connection
- ISOLATED
- Current Collector Cutoff Max
- 250μA
- Tedarikçi Cihaz Paketi
- SP4
- Maks. Çalışma Sıcaklığı
- + 100 C
- Max Power Dissipation
- 625W
- Montaj Tipi
- Chassis Mount
- Lifecycle Status
- Production (Last Updated: 2 months ago)
- Polaritychannel Type
- N-CHANNEL
- RoHS Durumu
- RoHS Compliant
- Pin Sayısı
- 12
- Maximum Gate Emitter Voltage
- 20 V
- Yayın Yılı
- 2006
- JESD-609 Kodu
- e1
- Parça Durumu
- Active
- Paket
- Bulk
- Terminal Formu
- UNSPECIFIED
- Collectoremitter Saturation Voltage
- 1.5 V
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Montaj
- Chassis Mount, Screw
- Vceon Max Vge Ic
- 1.9V @ 15V, 200A
- Montaj Stili
- Chassis Mount
- Number Of Elements
- 2
- Transistor Application
- POWER CONTROL
- Continuous Collector Current
- 290
- Collector Emitter Voltage Vceo
- 600V
- Ntc Thermistor
- Yes
- Qualification Status
- Not Qualified
- Ürün Durumu
- Active
- Birim Ağırlık
- 3.880136 oz
- Kılıf / Paket
- SP4
- Max Collector Current
- 290A
- Input
- Standard
