Specifications
- Number Of Elements
- 2
- Montaj Stili
- Chassis Mount
- Transistor Application
- POWER CONTROL
- Continuous Collector Current
- 280
- Collector Emitter Voltage Vceo
- 1.2kV
- Ntc Thermistor
- No
- JESD-609 Kodu
- e1
- Parça Durumu
- Active
- Paket
- Bulk
- Terminal Formu
- UNSPECIFIED
- Collectoremitter Saturation Voltage
- 1.7 V
- Montaj
- Chassis Mount, Screw
- Vceon Max Vge Ic
- 2.1V @ 15V, 200A
- Case Connection
- ISOLATED
- Current Collector Cutoff Max
- 350μA
- Tedarikçi Cihaz Paketi
- SP6
- Maks. Çalışma Sıcaklığı
- + 100 C
- Max Power Dissipation
- 890W
- Montaj Tipi
- Chassis Mount
- Lifecycle Status
- Production (Last Updated: 2 months ago)
- Polaritychannel Type
- N-CHANNEL
- RoHS Durumu
- RoHS Compliant
- Pin Sayısı
- 7
- Maximum Gate Emitter Voltage
- 20 V
- Yayın Yılı
- 2006
- Pin Sayısı
- 7
- Maks. Çalışma Sıcaklığı
- 150 °C
- RoHS
- Details
- Turn On Time
- 340 ns
- Element Configuration
- Dual
- Igbt Type
- Trench Field Stop
- Collectoremitter Breakdown Voltage
- 1.2kV
- Additional Feature
- AVALANCHE RATED
- Power Dissipation
- 890
- Turn Off Timenom Toff
- 610 ns
- Continuous Collector Current At25 C
- 280 A
- Minimum Operating Temperature
- - 40 C
- Voltage Collector Emitter Breakdown Max
- 1200V
- Input Capacitance
- 14nF
- Terminal Sayısı
- 7
