Specifications
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Terminal Formu
- UNSPECIFIED
- Collectoremitter Saturation Voltage
- 1.7 V
- Montaj
- Chassis Mount, Screw
- Vceon Max Vge Ic
- 2.1V @ 15V, 150A
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Parça Durumu
- Active
- Paket
- Bulk
- Transistor Application
- POWER CONTROL
- Continuous Collector Current
- 220
- Collector Emitter Voltage Vceo
- 1.2kV
- Ntc Thermistor
- Yes
- Qualification Status
- Not Qualified
- Number Of Elements
- 2
- Montaj Stili
- Chassis Mount
- Igbt Type
- Trench Field Stop
- Collectoremitter Breakdown Voltage
- 1.2kV
- Maks. Çalışma Sıcaklığı
- 150 °C
- RoHS
- Details
- Pin Sayısı
- 20
- Turn On Time
- 335 ns
- Element Configuration
- Dual
- Polaritychannel Type
- N-CHANNEL
- Lifecycle Status
- Production (Last Updated: 2 months ago)
- Montaj Tipi
- Chassis Mount
- Yayın Yılı
- 2009
- RoHS Durumu
- RoHS Compliant
- Pin Sayısı
- 25
- Maximum Gate Emitter Voltage
- 20 V
- Tedarikçi Cihaz Paketi
- SP3
- Maks. Çalışma Sıcaklığı
- + 100 C
- Case Connection
- ISOLATED
- Current Collector Cutoff Max
- 250μA
- Max Power Dissipation
- 833W
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Transistor Element Material
- SILICON
- Min. Çalışma Sıcaklığı
- -40 °C
- Configuration
- Half Bridge
- Power Max
- 833W
- Fabrika Tedarik Süresi
- 36 Weeks
