Specifications
- Turn On Time
- 180 ns
- Pin Sayısı
- 32
- RoHS
- Details
- Maks. Çalışma Sıcaklığı
- 175 °C
- Igbt Type
- Trench Field Stop
- Collectoremitter Breakdown Voltage
- 600V
- Max Power Dissipation
- 340W
- Turn On Delay Time
- 115 ns
- Case Connection
- ISOLATED
- Current Collector Cutoff Max
- 250μA
- Tedarikçi Cihaz Paketi
- SP3
- Maks. Çalışma Sıcaklığı
- + 175 C
- Pin Sayısı
- 25
- RoHS Durumu
- RoHS Compliant
- Maximum Gate Emitter Voltage
- 20 V
- Yayın Yılı
- 2006
- Montaj Tipi
- Chassis Mount
- Polaritychannel Type
- N-CHANNEL
- Lifecycle Status
- Production (Last Updated: 2 months ago)
- JESD-609 Kodu
- e1
- Parça Durumu
- Active
- Paket
- Bulk
- Montaj
- Chassis Mount, Screw
- Radyasyon Dayanımı
- No
- Vceon Max Vge Ic
- 1.9V @ 15V, 100A
- Terminal Formu
- UNSPECIFIED
- Collectoremitter Saturation Voltage
- 1.5V
- Number Of Elements
- 4
- Montaj Stili
- Chassis Mount
- Operating Temperature Range
- - 40 C to + 175 C
- Ntc Thermistor
- Yes
- Collector Emitter Voltage Vceo
- 600V
- Continuous Collector Current
- 150
- Transistor Application
- POWER CONTROL
- Max Collector Current
- 150A
- Input
- Standard
- Currentcollector Ic Max
- 150 A
- Turn Off Delay Time
- 225 ns
- Ürün Durumu
- Active
- Kurşunsuz
- Lead Free
