Specifications
- Transistor Element Material
- SILICON
- Çalışma Sıcaklığı
- -40°C~175°C TJ
- Configuration
- Half Bridge
- Min. Çalışma Sıcaklığı
- -40 °C
- Gateemitter Voltagemax
- 20V
- Power Max
- 340W
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 36 Weeks
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Turn Off Timenom Toff
- 370 ns
- Terminal Sayısı
- 12
- Input Capacitance
- 6.1nF
- Voltage Collector Emitter Breakdown Max
- 600 V
- Kurşunsuz Kodu
- yes
- Input Capacitance Cies Vce
- 6.1nF @ 25V
- Temel Ürün No
- APTGT100
- Terminal Kaplaması
- TIN SILVER COPPER
- Kılıf / Paket
- SP1
- Vcesatmax
- 1.9 V
- Ürün Durumu
- Active
- Currentcollector Ic Max
- 150 A
- Input
- Standard
- Max Collector Current
- 150A
- Terminal Pozisyonu
- UPPER
- Terminal Formu
- THROUGH-HOLE
- Montaj
- Chassis Mount, Screw
- Vceon Max Vge Ic
- 1.9V @ 15V, 100A
- Radyasyon Dayanımı
- No
- Paket
- Bulk
- Parça Durumu
- Active
- JESD-609 Kodu
- e1
- Transistor Application
- MOTOR CONTROL
- Continuous Collector Current
- 150
- Collector Emitter Voltage Vceo
- 600V
- Ntc Thermistor
- Yes
- Number Of Elements
- 2
- Igbt Type
- Trench Field Stop
- Collectoremitter Breakdown Voltage
- 600V
- Maks. Çalışma Sıcaklığı
- 175 °C
- RoHS
- Compliant
