Specifications
- Current Collector Cutoff Max
- 250μA
- Case Connection
- ISOLATED
- Tedarikçi Cihaz Paketi
- SP4
- Terminal Pozisyonu
- UPPER
- Max Power Dissipation
- 500W
- Montaj Tipi
- Chassis Mount
- Polaritychannel Type
- N-CHANNEL
- Pin Sayısı
- 14
- RoHS Durumu
- RoHS Compliant
- Pin Sayısı
- 20
- Ürün Durumu
- Obsolete
- Vcesatmax
- 3.7 V
- Maks. Çalışma Sıcaklığı
- 150°C
- Kılıf / Paket
- SP4
- Turn On Time
- 190 ns
- Max Collector Current
- 100A
- Input
- Standard
- Currentcollector Ic Max
- 100 A
- Input Capacitance Cies Vce
- 5.1nF @ 25V
- Kurşunsuz Kodu
- yes
- Collectoremitter Breakdown Voltage
- 1.2kV
- Igbt Type
- NPT
- Terminal Kaplaması
- TIN SILVER COPPER
- Number Of Elements
- 4
- Turn Off Timenom Toff
- 390 ns
- Transistor Application
- MOTOR CONTROL
- Ntc Thermistor
- Yes
- Collector Emitter Voltage Vceo
- 1.2kV
- Voltage Collector Emitter Breakdown Max
- 1200V
- Input Capacitance
- 5.1nF
- Terminal Sayısı
- 14
- Jesd30 Code
- R-XUFM-X14
- JESD-609 Kodu
- e1
- ECCN Kodu
- EAR99
- Parça Durumu
- Obsolete
- Paket
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Formu
- UNSPECIFIED
- Power Max
- 500 W
- Configuration
- Full Bridge Inverter
