Specifications
- Collector Emitter Voltage Vceo
- 600V
- Ntc Thermistor
- Yes
- Transistor Application
- MOTOR CONTROL
- Temperature Characteristics Code
- X7R
- Number Of Elements
- 4
- Montaj
- Chassis Mount, Screw
- Radyasyon Dayanımı
- No
- Vceon Max Vge Ic
- 2.45V @ 15V, 30A
- Terminal Formu
- UNSPECIFIED
- Parça Durumu
- Obsolete
- Paket
- Bulk
- JESD-609 Kodu
- e1
- Yayın Yılı
- 2012
- RoHS Durumu
- RoHS Compliant
- Pin Sayısı
- 12
- Polaritychannel Type
- N-CHANNEL
- Montaj Tipi
- Chassis Mount
- Max Power Dissipation
- 140W
- Tedarikçi Cihaz Paketi
- SP1
- Case Connection
- ISOLATED
- Current Collector Cutoff Max
- 250μA
- Package Shape
- RECTANGULAR PACKAGE
- Igbt Type
- NPT
- Collectoremitter Breakdown Voltage
- 600V
- Size Code
- 1812
- Dielectric Material
- CERAMIC
- Turn On Time
- 44 ns
- Number Of Terminals
- 2
- Maks. Çalışma Sıcaklığı
- 150°C
- Pin Sayısı
- 12
- Voltage Collector Emitter Breakdown Max
- 600 V
- Input Capacitance
- 1.35nF
- Terminal Sayısı
- 12
- Package Style
- SMT
- Turn Off Timenom Toff
- 111 ns
- Negative Tolerance
- 20
- Terminal Shape
- WRAPAROUND
- Configuration
- Full Bridge Inverter
- Min. Çalışma Sıcaklığı
- -40°C
- Power Max
- 140 W
