Specifications
- Voltage Forward Vf Max If
- 950mV @ 20A
- Rep Pk Reverse Voltagemax
- 100V
- Applications
- EFFICIENCY
- REACH Uyumluluk Kodu
- not_compliant
- Operating Temperature Junction
- -55°C~150°C
- Terminal Pozisyonu
- SINGLE
- Current Average Rectified Io
- 20A
- Diode Type
- Schottky
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- RoHS Durumu
- ROHS3 Compliant
- Number Of Phases
- 1
- Kurşunsuz Kodu
- yes
- Current Reverse Leakage Vr
- 50μA @ 100V
- Ambalaj
- Bulk
- Qualification Status
- Not Qualified
- Additional Feature
- LOW POWER LOSS
- Number Of Elements
- 2
- JESD-609 Kodu
- e3
- Kılıf / Paket
- TO-220-3 Isolated Tab
- ECCN Kodu
- EAR99
- Terminal Kaplaması
- MATTE TIN
- Pin Sayısı
- 3
- Diode Configuration
- 1 Pair Common Cathode
- HTS Kodu
- 8541.10.00.80
- Output Currentmax
- 20A
- Montaj Tipi
- Through Hole
- Parça Durumu
- Active
- Terminal Sayısı
- 3
- Yayın Yılı
- 2007
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Fabrika Tedarik Süresi
- 16 Weeks
- Speed
- Fast Recovery =< 500ns, > 200mA (Io)
- Voltage Dc Reverse Vr Max
- 100V
- Yüzey Montaj
- NO
- Nonrep Pk Forward Currentmax
- 150A
- Diode Element Material
- SILICON
- Jesd30 Code
- R-PSFM-T3
