Volume pricing
- 1+ pcs$36.15
- 10+ pcs$34.10
- 100+ pcs$32.17
- 500+ pcs$30.35
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Adımı
- 2.54mm
- JESD-609 Kodu
- e3
- Fonksiyon Sayısı
- 1
- Kurşunsuz Kodu
- yes
- Interface Ic Type
- BUFFER OR INVERTER BASED MOSFET DRIVER
- Max Output Current
- 1.5A
- Yayın Yılı
- 2002
- Gate Type
- N-Channel, P-Channel MOSFET
- RoHS Durumu
- ROHS3 Compliant
- ECCN Kodu
- EAR99
- Channel Type
- Single
- Fabrika Tedarik Süresi
- 10 Weeks
- High Side Driver
- YES
- Pin Sayısı
- 8
- Giriş Tipi
- Non-Inverting
- Turn Off Time
- 0.07 μs
- Propagation Delay
- 55 ns
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Besleme Gerilimi
- 5V
- Ambalaj
- Tube
- Kurşunsuz
- Lead Free
- Terminal Kaplaması
- Matte Tin (Sn)
- Nominal Supply Current
- 2.5mA
- Pin Sayısı
- 8
- Frekans
- 1MHz
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Turn On Time
- 0.06 μs
- Power Supplies
- 5V
- Rise Fall Time Typ
- 33ns 27ns
- Parça Durumu
- Active
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Genişlik
- 7.62mm
- Çalışma Sıcaklığı
- -55°C~125°C TA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Current Peak Output Source Sink
- 1.5A 1.5A
- Temel Parça No
- TC4627
- Driver Configuration
- High-Side or Low-Side
- Power Dissipation
- 800mW
- Besleme Gerilimi
- 4V~6V
