Volume pricing
- 1+ pcs$1.48
- 10+ pcs$1.40
- 100+ pcs$1.32
- 500+ pcs$1.25
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Channel Type
- Independent
- JESD-609 Kodu
- e3
- Fall Time Typ
- 6 ns
- Qualification Status
- Not Qualified
- Operating Supply Voltage
- 12V
- Rise Time
- 6ns
- Parça Durumu
- Active
- High Side Driver
- YES
- Turn On Time
- 10 μs
- Usage Level
- Industrial grade
- ECCN Kodu
- EAR99
- Terminal Kaplaması
- Matte Tin (Sn) - annealed
- Montaj
- Surface Mount
- Tepe Reflow Süresi (maks. sn)
- 40
- Tepe Reflow Sıcaklığı (°C)
- 260
- Terminal Formu
- NO LEAD
- Turn Off Time
- 10 μs
- Operating Supply Current
- 550μA
- Genişlik
- 4mm
- Driver Configuration
- Half-Bridge
- Temel Parça No
- MD1213
- Output Current
- 2A
- Current Peak Output Source Sink
- 2A 2A
- Terminal Sayısı
- 12
- Logic Voltagevil Vih
- 0.3V 1.2V
- Maks. Oturma Yüksekliği
- 1mm
- Rise Fall Time Typ
- 6ns 6ns
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Adımı
- 0.8mm
- Nominal Supply Current
- 550μA
- Terminal Pozisyonu
- QUAD
- Besleme Gerilimi
- 4.5V~13V
- Çalışma Sıcaklığı
- -20°C~125°C TJ
- Output Peak Current Limitnom
- 2A
- Giriş Tipi
- Non-Inverting
- Max Output Current
- 2A
- Frekans
- 100kHz
- Uzunluk
- 4mm
- Montaj Tipi
- Surface Mount
- Propagation Delay
- 7 ns
