Specifications
- Uzunluk
- 20mm
- Seri
- ATF15xx
- Delay Time Tpd1 Max
- 7.5ns
- Tepe Reflow Sıcaklığı (°C)
- 225
- Terminal Pozisyonu
- QUAD
- Terminal Sayısı
- 100
- Max Supply Voltage
- 5.25V
- Pin Sayısı
- 100
- Kurşunsuz
- Contains Lead
- Number Of Ios
- 64
- Tepe Reflow Süresi (maks. sn)
- 30
- Number Of Gates
- 1500
- Voltage Supply Internal
- 4.75V~5.25V
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Jtag Bst
- YES
- Min Supply Voltage
- 4.75V
- Min. Çalışma Sıcaklığı
- 0°C
- Temel Parça No
- ATF1504AS
- Terminal Formu
- GULL WING
- Programmable Logic Type
- EE PLD
- HTS Kodu
- 8542.39.00.01
- Kılıf / Paket
- 100-BQFP
- Parça Durumu
- Obsolete
- Maks. Çalışma Sıcaklığı
- 70°C
- Operating Supply Voltage
- 5V
- Besleme Gerilimi
- 5V
- Insystem Programmable
- YES
- Ambalaj
- Tray
- JESD-609 Kodu
- e0
- Pin Sayısı
- 100
- Montaj
- Surface Mount
- Genişlik
- 14mm
- Yayın Yılı
- 1997
- Maks. Oturma Yüksekliği
- 3.4mm
- Frequencymax
- 166.7MHz
- Programmable Type
- In System Programmable (min 10K program/erase cycles)
- Terminal Adımı
- 0.65mm
- Terminal Kaplaması
- Tin/Lead (Sn/Pb)
- Temperature Grade
- COMMERCIAL
- Number Of Macro Cells
- 64
