Specifications
- Reverse Voltagemax
- 5V
- Forward Currentmax
- 0.15A
- Yükseklik
- 1.3mm
- Wavelength Peak
- 636nm Red 525nm Green 470nm Blue
- Lens Size
- 4.25mm
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz
- Lead Free
- Fabrika Tedarik Süresi
- 12 Weeks
- Boyut / Ölçü
- 5.00mm Lx5.00mm W
- Pin Sayısı
- 6
- Voltage Forward Vf Typ
- 2.5V Red 3.5V Green 3.5V Blue
- Configuration
- Common Anode
- Operating Temperature Min
- -40°C
- Operating Temperature Max
- 85°C
- Lens Color
- Colorless
- Yayın Yılı
- 2013
- Lens Style
- Square with Flat Top
- Renk
- Red, Green, Blue (RGB)
- Optoelectronic Device Type
- TRIPLE COLOR LED
- Current Test
- 150mA Red 150mA Green 150mA Blue
- Montaj
- Surface Mount
- Millicandela Rating
- 3200mcd Red, 6300mcd Green, 1500mcd Blue
- Montaj Tipi
- Surface Mount
- Forward Voltagemax
- 3V
- Luminous Intensity
- 1.5 cd
- Lens Transparency
- Clear
- Ambalaj
- Tape & Reel (TR)
- Parça Durumu
- Active
- HTS Kodu
- 8541.40.20.00
- Reach Svhc
- No SVHC
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Viewing Angle
- 120°
- Kılıf / Paket
- 6-SMD, Gull Wing
