Specifications
- Max Voltage Rating Dc
- 350V
- Clamping Current
- 100A
- Insulation Resistance
- 1GOhm
- Varistor Voltage Max
- 473V
- Yükseklik
- 28mm
- Çap
- 20mm
- Capacitance Frequency
- 900pF @ 1MHz
- Max Output Current
- 10kA
- Ambalaj
- Bulk
- Max Surge Current
- 10kA
- Kurşunsuz
- Lead Free
- Seri
- TMOV®
- Terminal Sayısı
- 2
- Özellikler
- Thermally Protected
- RoHS Durumu
- ROHS3 Compliant
- Kapasitans
- 900pF
- Depth
- 9.5mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Clamping Voltage
- 710V
- Ambient Temperature Range High
- 85°C
- Kurşunsuz Kodu
- yes
- Number Of Circuits
- 1
- Çalışma Sıcaklığı
- -55°C~85°C TA
- Parça Durumu
- Active
- Varistor Voltage
- 387V
- Lead Length
- 25.4mm
- Varistor Voltage Typ
- 430V
- JESD-609 Kodu
- e3
- Yayın Yılı
- 2009
- Fabrika Tedarik Süresi
- 18 Weeks
- Voltage Rated Ac
- 275V
- Montaj
- Radial, Through Hole
- Lead Pitch
- 7.5mm
- Resistor Type
- VARISTOR
- Max Voltage Rating Ac
- 275V
- Kılıf / Paket
- Disc 20mm
- Montaj Tipi
- Through Hole
- Terminal Shape
- WIRE
- Maximum Dc Volts
- 350V
- Voltage Rated Dc
- 387V
