Specifications
- Configuration
- Half Bridge
- Element Configuration
- Dual
- ECCN Kodu
- EAR99
- Kılıf / Paket
- Module
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Fabrika Tedarik Süresi
- 10 Weeks
- Power Max
- 1500W
- Parça Durumu
- Active
- Max Power Dissipation
- 1.5kW
- Max Collector Current
- 700A
- Input
- Standard
- Yayın Yılı
- 2014
- Vceon Max Vge Ic
- 1.45V @ 15V, 600A (Typ)
- Weight
- 350.000009g
- Input Capacitance Cies Vce
- 39nF @ 25V
- Montaj
- Chassis Mount
- Montaj Tipi
- Chassis Mount
- Collector Emitter Voltage Vceo
- 1.45V
- Input Capacitance
- 39nF
- Polarity
- NPN
- Pin Sayısı
- 11
- Ntc Thermistor
- Yes
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Collectoremitter Saturation Voltage
- 1.45V
- Current Collector Cutoff Max
- 1mA
- REACH Uyumluluk Kodu
- unknown
- Collectoremitter Breakdown Voltage
- 600V
