Specifications
- Voltage Dc Reverse Vr Max
- 1800V
- Reverse Test Voltage
- 1800V
- Terminal Formu
- UNSPECIFIED
- Kılıf / Paket
- A-3 Module
- Nonrep Pk Forward Currentmax
- 2200A
- ECCN Kodu
- EAR99
- RoHS Durumu
- ROHS3 Compliant
- Montaj
- Chassis Mount
- Ambalaj
- Bulk
- Output Current
- 90A
- Yayın Yılı
- 2014
- Terminal Sayısı
- 3
- Diode Type
- Standard
- Reverse Currentmax
- 500μA
- Operating Temperature Junction
- -40°C~150°C
- Weight
- 110.000005g
- Number Of Elements
- 2
- Jesd30 Code
- R-CUFM-X3
- Additional Feature
- UL RECOGNISED
- Current Reverse Leakage Vr
- 500μA @ 1800V
- Power Dissipation Max
- 310W
- Maks. Çalışma Sıcaklığı
- 150°C
- Voltage Forward Vf Max If
- 1.6V @ 280A
- Number Of Phases
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- REACH Uyumluluk Kodu
- unknown
- Forward Voltage
- 1.6V
- Reverse Voltage Dc
- 1.8kV
- Diode Configuration
- 1 Pair Series Connection
- Terminal Pozisyonu
- UPPER
- Average Rectified Current
- 90A
- Max Reverse Voltage Dc
- 1.8kV
- Montaj Tipi
- Chassis Mount
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- Fabrika Tedarik Süresi
- 10 Weeks
- Min. Çalışma Sıcaklığı
- -40°C
- Diode Element Material
- SILICON
- Parça Durumu
- Active
- Breakdown Voltagemin
- 1800V
