LSIC2SD120A05

Specifications

Voltage Dc Reverse Vr Max

1200V

Seri

Gen2

Reverse Recovery Time

0ns

Operating Temperature Junction

-55°C~175°C

Ambalaj

Tube

HTS Kodu

8541.10.00.80

Current Reverse Leakage Vr

100μA @ 1200V

Kılıf / Paket

TO-220-2

Fabrika Tedarik Süresi

23 Weeks

Yüzey Montaj

NO

Capacitance Vr F

310pF @ 1V 1MHz

Current Average Rectified Io

17.5A DC

Jedec95 Code

TO-220AC

Additional Feature

PD-CASE

Reverse Currentmax

100μA

Operating Temperature Max

175°C

Diode Type

Silicon Carbide Schottky

RoHS Durumu

ROHS3 Compliant

Tepe Reflow Sıcaklığı (°C)

260

ECCN Kodu

EAR99

Forward Current

17.5A

Power Dissipation Max

100W

Configuration

SINGLE

Montaj Tipi

Through Hole

Applications

EFFICIENCY

Number Of Elements

1

Jesd30 Code

R-PSFM-T2

Speed

No Recovery Time > 500mA (Io)

Parça Durumu

Active

Rep Pk Reverse Voltagemax

1200V

Voltage Forward Vf Max If

1.8V @ 5A

Nem Hassasiyeti (MSL)

1 (Unlimited)

Tepe Reflow Süresi (maks. sn)

NOT SPECIFIED

Terminal Pozisyonu

SINGLE

Yayın Yılı

2017

Number Of Phases

1

REACH Uyumluluk Kodu

unknown

Case Connection

CATHODE

Terminal Sayısı

2
