Volume pricing
- 1+ pcs$1.74
- 10+ pcs$1.64
- 100+ pcs$1.55
- 500+ pcs$1.46
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Switching Voltage
- 300VDC -Max
- RoHS Durumu
- ROHS3 Compliant
- Coil Current
- 11.1mA
- Kontak Formu
- SPST-NO (1 Form A)
- Parça Durumu
- Active
- Physical Dimension
- 19.5mm x 7.22mm x 5.5mm
- Length Termination
- 0.003 inch
- Body Height
- 5.5mm
- Pcb Hole Count
- 8
- Body Length Or Diameter
- 19.5mm
- Çalışma Sıcaklığı
- -20°C~85°C
- Relay Type
- Reed
- Coilinput Supply Type
- DC
- Contact Voltagedcmax
- 200V
- Yayın Yılı
- 2007
- Contactoutput Supply Type
- DC
- Must Operate Voltage
- 16VDC
- Contact Rating Current
- 500mA
- ECCN Kodu
- EAR99
- Terminal
- PC Pin
- Coil Voltage
- 24VDC
- Operate Time
- 1ms
- Input Switching Control Type
- Random
- Relay Action
- MOMENTARY
- Kurşunsuz
- Lead Free
- Body Breadth
- 7.22 mm
- Ambalaj
- Tube
- HTS Kodu
- 8536.49.00.50
- Montaj Tipi
- Through Hole
- Coil Voltage Dc
- 24V
- Contact Dc Max Power Rating R Load
- 10W@300VDC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Dc Max Rating R Load
- .5A@200VDC
- Montaj
- Through Hole
- Release Time
- 1 ms
- Seri
- HE700
- Sealing
- HERMETICALLY SEALED
- Coil Power
- 264mW
- Fabrika Tedarik Süresi
- 23 Weeks
- Terminal Stili
- PC Pin
