Volume pricing
- 1+ pcs$2.81
- 10+ pcs$2.65
- 100+ pcs$2.50
- 500+ pcs$2.36
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Rating Current
- 500mA
- ECCN Kodu
- EAR99
- Contact Voltagedcmax
- 200V
- Contactoutput Supply Type
- DC
- Uzunluk
- 19.5mm
- Yayın Yılı
- 2007
- Must Operate Voltage
- 3.75VDC
- Input Switching Control Type
- Random
- Operate Time
- 1ms
- Relay Action
- MOMENTARY
- Kurşunsuz
- Lead Free
- Ambalaj
- Tube
- Body Breadth
- 7.22 mm
- Terminal
- PC Pin
- Coil Voltage
- 5VDC
- Parça Durumu
- Active
- Coil Current
- 10mA
- Kontak Formu
- SPST-NO (1 Form A)
- Physical Dimension
- 19.5mm x 7.22mm x 5.5mm
- Body Height
- 5.5mm
- Switching Voltage
- 300VDC -Max
- RoHS Durumu
- ROHS3 Compliant
- Relay Type
- Reed
- Coilinput Supply Type
- DC
- Pcb Hole Count
- 8
- Çalışma Sıcaklığı
- -20°C~85°C
- Reference Standard
- CUL; UL
- REACH Uyumluluk Kodu
- unknown
- Pin Sayısı
- 4
- Terminal Stili
- PC Pin
- Coilresistance
- 500Ohm
- Throw Configuration
- SPST
- Must Release Voltage
- 0.5VDC
- Terminal Sayısı
- 8
- Coil Type
- Non Latching
- Montaj
- Through Hole
- Depth
- 9.52mm
- Release Time
- 1 ms
- Montaj Tipi
- Through Hole
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
