Volume pricing
- 1+ pcs$6.91
- 10+ pcs$6.52
- 100+ pcs$6.15
- 500+ pcs$5.81
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Currentdcmax
- 0.25A
- Coilresistance
- 200Ohm
- Pin Sayısı
- 8
- Terminal Stili
- PC Pin
- Reference Standard
- CUL; UL
- Insulation Resistance
- 10000000000Ohm
- Coil Type
- Non Latching
- Contact Resistance
- 200mOhm
- Terminal Sayısı
- 8
- Must Release Voltage
- 0.5VDC
- Throw Configuration
- SPDT
- Coil Voltage Dc
- 5V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Release Time
- 3 ms
- Depth
- 9.52mm
- Genişlik
- 7.24mm
- Sealing
- HERMETICALLY SEALED
- Coil Power
- 125mW
- Fabrika Tedarik Süresi
- 23 Weeks
- Kılıf / Paket
- DIP
- Seri
- HE700
- Yayın Yılı
- 2001
- Uzunluk
- 20.19mm
- Contactoutput Supply Type
- DC
- Must Operate Voltage
- 3.75VDC
- ECCN Kodu
- EAR99
- Coil Voltage
- 5VDC
- Terminal
- PC Pin
- Body Breadth
- 7.22 mm
- Ambalaj
- Tube
- Operate Time
- 3ms
- Input Switching Control Type
- Random
- Relay Action
- MOMENTARY
- RoHS Durumu
- ROHS3 Compliant
- Yükseklik
- 7.75mm
- Voltage Rated Dc
- 175V
- Additional Feature
- WITH COIL DIODE AND ELECTRO STATIC SHIELD
- Switching Voltage
- 175VDC -Max
