Volume pricing
- 1+ pcs$3.44
- 10+ pcs$3.25
- 100+ pcs$3.06
- 500+ pcs$2.89
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2007
- Must Operate Voltage
- 3.75VDC
- Contact Voltagedcmax
- 200V
- ECCN Kodu
- EAR99
- Contact Rating Current
- 500mA
- Coil Voltage
- 5VDC
- Terminal
- PC Pin
- Dielectric Strength Between Coil And Contacts
- 500 Vrms
- Ambalaj
- Tube
- Body Breadth
- 7.24 mm
- Input Switching Control Type
- Random
- Operate Time
- 1ms
- Relay Action
- MOMENTARY
- RoHS Durumu
- ROHS3 Compliant
- Switching Voltage
- 200VDC -Max
- Length Termination
- 0.003 inch
- Body Height
- 7.5mm
- Özellikler
- Electrostatic Shield
- Kontak Formu
- SPST-NO (1 Form A)
- Coil Current
- 10mA
- Parça Durumu
- Active
- Physical Dimension
- 19.05mm x 7.24mm x 7.5mm
- Pcb Hole Count
- 4
- Çalışma Sıcaklığı
- -40°C~85°C
- Body Length Or Diameter
- 19.05mm
- Coilinput Supply Type
- DC
- Relay Type
- Reed
- Coilresistance
- 500Ohm
- Terminal Stili
- PC Pin
- Reference Standard
- UL
- REACH Uyumluluk Kodu
- unknown
- Insulation Resistance
- 10000000000Ohm
- Coil Type
- Non Latching
- Contact Resistance
- 150mOhm
- Terminal Sayısı
- 4
- Must Release Voltage
- 0.5VDC
- Dielectric Strength Between Open Contacts
- 250 Vrms
- Throw Configuration
- SPST
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Coil Voltage Dc
- 5V
