Specifications
- Terminal
- Radial
- Maks. Oturma Yüksekliği
- 1.154 29.30mm
- Onay Kuruluşu
- cURus, TUV
- Akım Değeri
- 40A
- Lead Pitch
- 10.2mm
- Parça Durumu
- Active
- JESD-609 Kodu
- e3
- Yüzey Montaj
- NO
- Power Dissipation
- 2.8W
- Voltage Rated Dc
- 72V
- Seri
- POLY-FUSE®, 72R
- Terminal Sayısı
- 2
- Ambalaj
- Bulk
- Montaj Tipi
- Through Hole
- Max Current Rating
- 40A
- Time To Trip
- 19.8s
- Thermistor Application
- OVERLOAD PROTECTION
- ECCN Kodu
- EAR99
- Hold Current
- 3A
- Tip
- Polymeric
- Terminal Shape
- WIRE
- Fabrika Tedarik Süresi
- 12 Weeks
- Direnç
- 100mOhm
- RoHS Durumu
- ROHS3 Compliant
- Kılıf / Paket
- Radial, Disc
- Resistance Post Trip R1 Max
- 100mOhm
- Çalışma Sıcaklığı
- -40°C~85°C
- Reach Svhc
- No SVHC
- REACH Uyumluluk Kodu
- unknown
- Current Hold Ih Max
- 3A
- Operating Supply Voltage
- 72V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- HTS Kodu
- 8533.40.80.70
- Lead Spacing
- 0.402 10.20mm
- Resistance Initial Ri Min
- 40mOhm
- Boyut / Ölçü
- 0.910Dia x 0.122 T 23.11mmx3.10mm
- Terminal Kaplaması
- Tin (Sn)
- Additional Feature
- 0.04 TO 0.1 OHMS MEASURED AT 23 DEG CEL
- Yayın Yılı
- 2010
- Trip Current
- 6A
