Specifications
- Yayın Yılı
- 2008
- Trip Current
- 2.7A
- Terminal Kaplaması
- Tin (Sn)
- Additional Feature
- 0.12 TO 0.3 OHMS MEASURED AT 23 DEG CEL
- Boyut / Ölçü
- 0.535Dia x 0.122 T 13.58mmx3.10mm
- Lead Spacing
- 0.201 5.10mm
- Resistance Initial Ri Min
- 120mOhm
- HTS Kodu
- 8533.40.80.70
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Supply Voltage
- 72V
- Çalışma Sıcaklığı
- -40°C~85°C
- REACH Uyumluluk Kodu
- unknown
- Resistance Post Trip R1 Max
- 300mOhm
- Kılıf / Paket
- Radial, Disc
- Direnç
- 300mOhm
- RoHS Durumu
- ROHS3 Compliant
- Terminal Shape
- WIRE
- Fabrika Tedarik Süresi
- 12 Weeks
- Tip
- Polymeric
- Hold Current
- 1.35A
- ECCN Kodu
- EAR99
- Thermistor Application
- OVERLOAD PROTECTION
- Max Current Rating
- 40A
- Time To Trip
- 9.6s
- Montaj Tipi
- Through Hole
- Ambalaj
- Bulk
- Seri
- POLY-FUSE®, 72R
- Terminal Sayısı
- 2
- Voltage Rated Dc
- 72V
- JESD-609 Kodu
- e3
- Yüzey Montaj
- NO
- Power Dissipation
- 1.7W
- Parça Durumu
- Active
- Onay Kuruluşu
- cURus, TUV
- Terminal
- Radial
- Maks. Oturma Yüksekliği
- 0.780 19.80mm
