Specifications
- Hold Current
- 1.85mA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Boyut / Ölçü
- 0.660Dia x 0.122 T 16.76mmx3.10mm
- Max Current Rating
- 40A
- Reach Svhc
- Unknown
- RoHS Durumu
- ROHS3 Compliant
- Trip Current
- 3.7A
- Onay Kuruluşu
- cURus, TUV
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Thickness
- 3.05mm
- Power Dissipation
- 2.1W
- Terminal Sayısı
- 2
- Working Voltage
- 60V
- Operating Supply Voltage
- 60V
- Max Voltage Rating Dc
- 60V
- Tip
- Polymeric
- Lead Spacing
- 0.201 5.10mm
- Kurşunsuz Kodu
- yes
- Resistance Initial Ri Min
- 80mOhm
- Terminal Shape
- WIRE
- Yükseklik
- 22.9mm
- Time To Trip
- 12.6s
- Lead Pitch
- 5.1mm
- Direnç
- 190mOhm
- Yayın Yılı
- 2008
- Maks. Oturma Yüksekliği
- 0.906 23.00mm
- Additional Feature
- RESISTANCE RANGE(RMIN-R1MAX)OHM: 0.08-0.19
- Voltage Rated Dc
- 60V
- Terminal Kaplaması
- Tin (Sn)
- Akım Değeri
- 1.85A
- Kılıf / Paket
- Radial, Disc
- Thermistor Application
- OVERLOAD PROTECTION
- Yüzey Montaj
- NO
- Montaj Tipi
- Through Hole
- Seri
- POLY-FUSE®, 60R
- Resistance Post Trip R1 Max
- 190mOhm
- Ambalaj
- Bulk
- Fabrika Tedarik Süresi
- 12 Weeks
- Çalışma Sıcaklığı
- -40°C~85°C
