Volume pricing
- 1+ pcs$0.87
- 10+ pcs$0.83
- 100+ pcs$0.78
- 500+ pcs$0.73
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Reach Svhc
- No SVHC
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 40A
- Boyut / Ölçü
- 0.512Dia x 0.122 T 13.00mmx3.10mm
- Parça Durumu
- Active
- Onay Kuruluşu
- cURus, TUV
- Trip Current
- 2.2A
- Kurşunsuz
- Lead Free
- Hold Current
- 1.1A
- Tip
- Polymeric
- Working Voltage
- 60V
- Max Voltage Rating Dc
- 60V
- Operating Supply Voltage
- 60V
- Resistance Initial Ri Min
- 150mOhm
- Terminal Shape
- WIRE
- Kurşunsuz Kodu
- yes
- Lead Spacing
- 0.201 5.10mm
- Thickness
- 3.05mm
- Terminal Sayısı
- 2
- Power Dissipation
- 1.5W
- Voltage Rated Dc
- 60V
- Terminal Kaplaması
- Matte Tin (Sn)
- Thermistor Application
- OVERLOAD PROTECTION
- Kılıf / Paket
- Radial, Disc
- Akım Değeri
- 1.1A
- HTS Kodu
- 8533.40.80.70
- Lead Pitch
- 5.1mm
- Time To Trip
- 8.2s
- Yükseklik
- 18mm
- Maks. Oturma Yüksekliği
- 0.717 18.20mm
- Additional Feature
- RESISTANCE RANGE(RMIN-R1MAX)OHM: 0.15-0.38
- Yayın Yılı
- 2008
- Direnç
- 380mOhm
- Fabrika Tedarik Süresi
- 12 Weeks
- ECCN Kodu
- EAR99
- Terminal
- Radial
- Çalışma Sıcaklığı
- -40°C~85°C
- JESD-609 Kodu
- e3
- Seri
- POLY-FUSE®, 60R
