Specifications
- Thickness
- 3.05mm
- Power Dissipation
- 990mW
- Terminal Sayısı
- 2
- Working Voltage
- 60V
- Max Voltage Rating Dc
- 60V
- Operating Supply Voltage
- 60V
- Tip
- Polymeric
- Current Hold Ih Max
- 900mA
- Lead Spacing
- 0.201 5.10mm
- Kurşunsuz Kodu
- yes
- Resistance Initial Ri Min
- 200mOhm
- Terminal Shape
- WIRE
- Hold Current
- 900mA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Boyut / Ölçü
- 0.441Dia x 0.122 T 11.20mmx3.10mm
- Max Current Rating
- 40A
- Reach Svhc
- Unknown
- RoHS Durumu
- ROHS3 Compliant
- Trip Current
- 1.8A
- Onay Kuruluşu
- cURus, TUV
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Yüzey Montaj
- NO
- Montaj Tipi
- Through Hole
- Packing Method
- AMMO PACK
- Seri
- POLY-FUSE®, 60R
- Ambalaj
- Tape & Box (TB)
- Resistance Post Trip R1 Max
- 470mOhm
- Fabrika Tedarik Süresi
- 12 Weeks
- Çalışma Sıcaklığı
- -40°C~85°C
- JESD-609 Kodu
- e3
- Terminal
- Radial
- Yükseklik
- 15.8mm
- Time To Trip
- 7.2s
- Lead Pitch
- 5.1mm
- Yayın Yılı
- 2003
- Direnç
- 470mOhm
- Maks. Oturma Yüksekliği
- 0.622 15.80mm
- Additional Feature
- RESISTANCE RANGE(RMIN-R1MAX)OHM: 0.2-0.47
- Voltage Rated Dc
- 60V
