Volume pricing
- 1+ pcs$0.27
- 10+ pcs$0.25
- 100+ pcs$0.24
- 500+ pcs$0.23
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Trip Current
- 1.3A
- Onay Kuruluşu
- cURus, TUV
- RoHS Durumu
- ROHS3 Compliant
- Reach Svhc
- Unknown
- Boyut / Ölçü
- 0.370Dia x 0.122 T 9.40mmx3.10mm
- Max Current Rating
- 40A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Hold Current
- 650mA
- Terminal Shape
- WIRE
- Resistance Initial Ri Min
- 310mOhm
- Kurşunsuz Kodu
- yes
- Lead Spacing
- 0.201 5.10mm
- Tip
- Polymeric
- Operating Supply Voltage
- 60V
- Max Voltage Rating Dc
- 60V
- Working Voltage
- 60V
- Terminal Sayısı
- 2
- Power Dissipation
- 880mW
- Thickness
- 3.05mm
- Thermistor Application
- OVERLOAD PROTECTION
- Kılıf / Paket
- Radial, Disc
- Akım Değeri
- 650mA
- Terminal Kaplaması
- Matte Tin (Sn)
- Voltage Rated Dc
- 60V
- Additional Feature
- RESISTANCE RANGE(RMIN-R1MAX)OHM: 0.31-0.72
- Maks. Oturma Yüksekliği
- 0.571 14.50mm
- Yayın Yılı
- 2008
- Direnç
- 720mOhm
- Lead Pitch
- 5.1mm
- Time To Trip
- 5.3s
- Yükseklik
- 14.5mm
- Terminal
- Radial
- JESD-609 Kodu
- e3
- Çalışma Sıcaklığı
- -40°C~85°C
- Fabrika Tedarik Süresi
- 12 Weeks
- Resistance Post Trip R1 Max
- 720mOhm
- Ambalaj
- Bulk
- Seri
- POLY-FUSE®, 60R
