Volume pricing
- 1+ pcs$0.28
- 10+ pcs$0.27
- 100+ pcs$0.25
- 500+ pcs$0.24
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Hold Current
- 500mA
- Kurşunsuz
- Lead Free
- Trip Current
- 1A
- Onay Kuruluşu
- cURus, TUV
- Parça Durumu
- Active
- Boyut / Ölçü
- 0.311Dia x 0.122 T 7.90mmx3.10mm
- Max Current Rating
- 40A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Reach Svhc
- Unknown
- Power Dissipation
- 770mW
- Terminal Sayısı
- 2
- Thickness
- 3.05mm
- Current Hold Ih Max
- 500mA
- Lead Spacing
- 0.201 5.10mm
- Kurşunsuz Kodu
- yes
- Terminal Shape
- WIRE
- Resistance Initial Ri Min
- 500mOhm
- Max Voltage Rating Dc
- 60V
- Operating Supply Voltage
- 60V
- Working Voltage
- 60V
- Tip
- Polymeric
- Direnç
- 1.17Ohm
- Yayın Yılı
- 2003
- Additional Feature
- RESISTANCE RANGE(RMIN-R1MAX)OHM: 0.5-1.17
- Maks. Oturma Yüksekliği
- 0.539 13.70mm
- Yükseklik
- 13.7mm
- Time To Trip
- 4s
- Lead Pitch
- 5.1mm
- HTS Kodu
- 8533.40.80.70
- Akım Değeri
- 40A
- Kılıf / Paket
- Radial, Disc
- Thermistor Application
- OVERLOAD PROTECTION
- Terminal Kaplaması
- Matte Tin (Sn)
- Voltage Rated Dc
- 60V
- Resistance Post Trip R1 Max
- 1.17Ohm
- Ambalaj
- Tape & Box (TB)
- Packing Method
- AMMO PACK
- Yüzey Montaj
- NO
- Montaj Tipi
- Through Hole
