Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 12 Weeks
- ECCN Kodu
- EAR99
- Çalışma Sıcaklığı
- -40°C~85°C
- JESD-609 Kodu
- e3
- Terminal
- Radial
- Yüzey Montaj
- NO
- Montaj Tipi
- Through Hole
- Seri
- POLY-FUSE®, 60R
- Resistance Post Trip R1 Max
- 1.29Ohm
- Ambalaj
- Bulk
- Voltage Rated Dc
- 60V
- Terminal Kaplaması
- Tin (Sn)
- Akım Değeri
- 400mA
- Thermistor Application
- OVERLOAD PROTECTION
- Kılıf / Paket
- Radial, Disc
- Time To Trip
- 3.8s
- Yükseklik
- 13.5mm
- HTS Kodu
- 8533.40.80.70
- Lead Pitch
- 5.1mm
- Yayın Yılı
- 2005
- Direnç
- 1.29Ohm
- Maks. Oturma Yüksekliği
- 0.532 13.50mm
- Additional Feature
- RESISTANCE RANGE(RMIN-R1MAX)OHM: 0.55-1.29
- Working Voltage
- 60V
- Operating Supply Voltage
- 60V
- Max Voltage Rating Dc
- 60V
- Tip
- Polymeric
- Lead Spacing
- 0.201 5.10mm
- Kurşunsuz Kodu
- yes
- Resistance Initial Ri Min
- 550mOhm
- Terminal Shape
- WIRE
- Thickness
- 3.05mm
- Power Dissipation
- 560mW
- Terminal Sayısı
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 40A
- Boyut / Ölçü
- 0.299Dia x 0.122 T 7.60mmx3.10mm
- Reach Svhc
- Unknown
- RoHS Durumu
- ROHS3 Compliant
- Onay Kuruluşu
- cURus, TUV
