Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Sayısı
- 2
- Power Dissipation
- 480mW
- Thickness
- 3.05mm
- Terminal Shape
- WIRE
- Resistance Initial Ri Min
- 3.3Ohm
- Current Hold Ih Max
- 170mA
- Lead Spacing
- 0.201 5.10mm
- Tip
- Polymeric
- Max Voltage Rating Dc
- 60V
- Operating Supply Voltage
- 60V
- Working Voltage
- 60V
- Hold Current
- 170mA
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Trip Current
- 340mA
- Onay Kuruluşu
- cURus
- RoHS Durumu
- ROHS3 Compliant
- Reach Svhc
- No SVHC
- Boyut / Ölçü
- 0.291Dia x 0.122 T 7.40mmx3.10mm
- Max Current Rating
- 40A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Resistance Post Trip R1 Max
- 8Ohm
- Seri
- POLY-FUSE®, 60R
- Yüzey Montaj
- NO
- Montaj Tipi
- Through Hole
- Terminal
- Radial
- JESD-609 Kodu
- e3
- Çalışma Sıcaklığı
- -40°C~85°C
- Fabrika Tedarik Süresi
- 12 Weeks
- Additional Feature
- RESISTANCE RANGE(RMIN-R1MAX)OHM: 3.3-8
- Maks. Oturma Yüksekliği
- 0.500 12.70mm
- Direnç
- 8Ohm
- Yayın Yılı
- 2005
- Lead Pitch
- 510μm
- Yükseklik
- 12.7mm
- Time To Trip
- 3s
- Thermistor Application
- OVERLOAD PROTECTION
- Kılıf / Paket
- Radial, Disc
- Akım Değeri
- 40A
