Specifications
- Thickness
- 3.05mm
- Terminal Sayısı
- 2
- Power Dissipation
- 380mW
- Tip
- Polymeric
- Working Voltage
- 60V
- Max Voltage Rating Dc
- 60V
- Operating Supply Voltage
- 60V
- Resistance Initial Ri Min
- 2.5Ohm
- Terminal Shape
- WIRE
- Current Hold Ih Max
- 100mA
- Lead Spacing
- 0.201 5.10mm
- Kurşunsuz Kodu
- yes
- Hold Current
- 100mA
- Reach Svhc
- Unknown
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Boyut / Ölçü
- 0.291Dia x 0.122 T 7.40mmx3.10mm
- Max Current Rating
- 40A
- Parça Durumu
- Active
- Trip Current
- 200mA
- Onay Kuruluşu
- cURus
- Kurşunsuz
- Lead Free
- Seri
- POLY-FUSE®, 60R
- Montaj Tipi
- Through Hole
- Yüzey Montaj
- NO
- Packing Method
- AMMO PACK
- Ambalaj
- Tape & Box (TB)
- Resistance Post Trip R1 Max
- 7.5Ohm
- Fabrika Tedarik Süresi
- 12 Weeks
- ECCN Kodu
- EAR99
- Terminal
- Radial
- Çalışma Sıcaklığı
- -40°C~85°C
- JESD-609 Kodu
- e3
- HTS Kodu
- 8533.40.80.70
- Lead Pitch
- 5.1mm
- Yükseklik
- 12.7mm
- Time To Trip
- 4s
- Maks. Oturma Yüksekliği
- 0.500 12.70mm
- Additional Feature
- RESISTANCE RANGE(RMIN-R1MAX)OHM: 2.5-7.5
- Direnç
- 7.5Ohm
