Specifications
- Tip
- Polymeric
- Resistance Post Trip R1 Max
- 17Ohm
- Montaj Tipi
- Through Hole
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Current Hold Ih Max
- 150mA
- Direnç
- 22Ohm
- Kılıf / Paket
- Radial, Disc
- Terminal Shape
- WIRE
- Ambalaj
- Bulk
- Additional Feature
- 6 TO 17 OHMS MEASURED AT 20 DEG CEL
- Resistance Initial Ri Min
- 6Ohm
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- JESD-609 Kodu
- e3
- Seri
- POLY-FUSE®, 600R
- HTS Kodu
- 8533.40.80.70
- Terminal Kaplaması
- Matte Tin (Sn)
- Terminal Sayısı
- 2
- Voltage Max
- 60V 600V Int
- Terminal
- Radial
- RoHS Durumu
- ROHS3 Compliant
- Çalışma Sıcaklığı
- -40°C~85°C
- Operating Supply Voltage
- 600V
- Time To Trip
- 4s
- Lead Spacing
- 0.201 5.10mm
- Yüzey Montaj
- NO
- Power Dissipation
- 1W
- Yayın Yılı
- 2006
- Kurşunsuz Kodu
- yes
- Voltage Rated Dc
- 60V
- Onay Kuruluşu
- cURus, TUV
- Trip Current
- 300mA
- ECCN Kodu
- EAR99
- Hold Current
- 150mA
- Reach Svhc
- No SVHC
- Thermistor Application
- OVERLOAD PROTECTION
- Max Current Rating
- 3A
- Boyut / Ölçü
- 0.354Lx0.181W 9.00mmx4.60mm
- Lead Pitch
- 5.1mm
- Maks. Oturma Yüksekliği
- 0.492 12.50mm
