Specifications
- Additional Feature
- FLAME PROOF, MINIMUM RESISTANCE IS 0.005 OHMS
- Current Hold Ih Max
- 8A
- Akım Değeri
- 40A
- Working Voltage
- 30V
- Seri
- POLY-FUSE®, 30R
- Terminal Sayısı
- 2
- Çalışma Sıcaklığı
- -40°C~85°C
- Resistance Post Trip R1 Max
- 20mOhm
- Terminal
- Radial
- Lead Spacing
- 0.402 10.20mm
- Tip
- Polymeric
- Time To Trip
- 18.8s
- Parça Durumu
- Active
- Onay Kuruluşu
- cURus, TUV
- Boyut / Ölçü
- 0.850Lx0.118W 21.60mmx3.00mm
- Trip Current
- 16A
- Yayın Yılı
- 2010
- JESD-609 Kodu
- e3
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Max Current Rating
- 40A
- Ambalaj
- Bulk
- Yükseklik
- 29.2mm
- Terminal Shape
- WIRE
- Resistance Initial Ri Min
- 5mOhm
- Reach Svhc
- No SVHC
- Power Dissipation
- 4W
- Montaj Tipi
- Through Hole
- Kılıf / Paket
- Radial, Disc
- Kurşunsuz
- Lead Free
- Fabrika Tedarik Süresi
- 12 Weeks
- Hold Current
- 8A
- Max Voltage Rating Dc
- 30V
- Operating Supply Voltage
- 30V
- Lead Pitch
- 10.2mm
- Maks. Oturma Yüksekliği
- 1.224 31.10mm
- Voltage Rated Dc
- 30V
- Terminal Kaplaması
- Matte Tin (Sn)
- Thermistor Application
- OVERCURRENT PROTECTION
- Yüzey Montaj
- NO
