Volume pricing
- 1+ pcs$1.07
- 10+ pcs$1.01
- 100+ pcs$0.95
- 500+ pcs$0.90
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Onay Kuruluşu
- cURus, TUV
- Boyut / Ölçü
- 0.551Lx0.118W 14.00mmx3.00mm
- ECCN Kodu
- EAR99
- Pin Sayısı
- 2
- JESD-609 Kodu
- e3
- Trip Current
- 8A
- Yayın Yılı
- 2008
- Çalışma Sıcaklığı
- -40°C~85°C
- Akım Değeri
- 4A
- Working Voltage
- 30V
- Seri
- POLY-FUSE®, 30R
- Terminal Sayısı
- 2
- Additional Feature
- FLAME PROOF, MINIMUM RESISTANCE IS 0.01 OHMS
- Parça Durumu
- Active
- Time To Trip
- 12.7s
- Lead Spacing
- 0.201 5.10mm
- Terminal
- Radial
- Resistance Post Trip R1 Max
- 50mOhm
- Tip
- Polymeric
- Lead Pitch
- 5.1mm
- Max Voltage Rating Dc
- 30V
- Operating Supply Voltage
- 30V
- Hold Current
- 4A
- Kurşunsuz
- Lead Free
- Fabrika Tedarik Süresi
- 12 Weeks
- Yüzey Montaj
- NO
- Thickness
- 3.05mm
- RoHS Durumu
- ROHS3 Compliant
- Direnç
- 50mOhm
- Thermistor Application
- OVERCURRENT PROTECTION
- Terminal Kaplaması
- Matte Tin (Sn)
- Voltage Rated Dc
- 30V
- Maks. Oturma Yüksekliği
- 0.866 22.00mm
- Yükseklik
- 20.1mm
- Terminal Shape
- WIRE
- Max Current Rating
- 40A
- Ambalaj
- Bulk
- Max Power Dissipation
- 2.5W
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
