Volume pricing
- 1+ pcs$0.66
- 10+ pcs$0.62
- 100+ pcs$0.58
- 500+ pcs$0.55
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Onay Kuruluşu
- cURus, TUV
- Boyut / Ölçü
- 0.449Lx0.118W 11.40mmx3.00mm
- JESD-609 Kodu
- e3
- Trip Current
- 6A
- Yayın Yılı
- 2010
- Akım Değeri
- 40A
- Terminal Sayısı
- 2
- Seri
- POLY-FUSE®, 30R
- Çalışma Sıcaklığı
- -40°C~85°C
- Additional Feature
- FLAME PROOF, MINIMUM RESISTANCE IS 0.02 OHMS
- Current Hold Ih Max
- 3A
- Time To Trip
- 10.8s
- Parça Durumu
- Active
- Packing Method
- AMMO PACK
- Resistance Post Trip R1 Max
- 80mOhm
- Lead Spacing
- 0.201 5.10mm
- Terminal
- Radial
- Tip
- Polymeric
- Lead Pitch
- 5.1mm
- Hold Current
- 3A
- Fabrika Tedarik Süresi
- 12 Weeks
- Kurşunsuz
- Lead Free
- Max Voltage Rating Dc
- 30V
- Operating Supply Voltage
- 30V
- Thermistor Application
- OVERCURRENT PROTECTION
- Yüzey Montaj
- NO
- Direnç
- 80mOhm
- RoHS Durumu
- ROHS3 Compliant
- Thickness
- 3.05mm
- Maks. Oturma Yüksekliği
- 0.756 19.20mm
- Voltage Rated Dc
- 30V
- Terminal Kaplaması
- Matte Tin (Sn)
- Yükseklik
- 7.27mm
- Terminal Shape
- WIRE
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 40A
- Ambalaj
- Tape & Box (TB)
- Power Dissipation
- 2W
- Montaj Tipi
- Through Hole
