Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Lead Pitch
- 5.1mm
- Hold Current
- 2.5A
- Fabrika Tedarik Süresi
- 12 Weeks
- Kurşunsuz
- Lead Free
- Max Voltage Rating Dc
- 30V
- Thermistor Application
- OVERCURRENT PROTECTION
- Yüzey Montaj
- NO
- Thickness
- 3.05mm
- RoHS Durumu
- ROHS3 Compliant
- Direnç
- 70mOhm
- Maks. Oturma Yüksekliği
- 0.720 18.30mm
- Terminal Kaplaması
- Matte Tin (Sn)
- Yükseklik
- 18.3mm
- Terminal Shape
- WIRE
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 40A
- Ambalaj
- Tape & Box (TB)
- HTS Kodu
- 8533.40.80.70
- Power Dissipation
- 1.2W
- Kılıf / Paket
- Radial, Disc
- Montaj Tipi
- Through Hole
- Resistance Initial Ri Min
- 20mOhm
- Onay Kuruluşu
- cURus, TUV
- Boyut / Ölçü
- 0.449Lx0.118W 11.40mmx3.00mm
- ECCN Kodu
- EAR99
- JESD-609 Kodu
- e3
- Trip Current
- 5A
- Yayın Yılı
- 2008
- Akım Değeri
- 40A
- Working Voltage
- 30V
- Seri
- POLY-FUSE®, 30R
- Terminal Sayısı
- 2
- Çalışma Sıcaklığı
- -40°C~85°C
- Additional Feature
- FLAME PROOF, MINIMUM RESISTANCE IS 0.02 OHMS
- Current Hold Ih Max
- 2.5A
- Time To Trip
- 10.3s
- Parça Durumu
- Active
- Packing Method
- AMMO PACK
- Lead Spacing
- 0.118 3.00mm
