Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2007
- Trip Current
- 3.7A
- JESD-609 Kodu
- e3
- ECCN Kodu
- EAR99
- Boyut / Ölçü
- 0.402Lx0.118W 10.20mmx3.00mm
- Onay Kuruluşu
- cURus, TUV
- Tip
- Polymeric
- Resistance Post Trip R1 Max
- 90mOhm
- Terminal
- Radial
- Lead Spacing
- 0.201 5.10mm
- Time To Trip
- 8.7s
- Packing Method
- AMMO PACK
- Parça Durumu
- Active
- Additional Feature
- FLAME PROOF, MINIMUM RESISTANCE IS 0.03 OHMS
- Current Hold Ih Max
- 1.85A
- Seri
- POLY-FUSE®, 30R
- Terminal Sayısı
- 2
- Akım Değeri
- 40A
- Çalışma Sıcaklığı
- -40°C~85°C
- Maks. Oturma Yüksekliği
- 0.618 15.70mm
- Voltage Rated Dc
- 30V
- Terminal Kaplaması
- Matte Tin (Sn)
- Thermistor Application
- OVERCURRENT PROTECTION
- Direnç
- 90mOhm
- RoHS Durumu
- ROHS3 Compliant
- Thickness
- 3.05mm
- Yüzey Montaj
- NO
- Hold Current
- 1.85A
- Fabrika Tedarik Süresi
- 12 Weeks
- Kurşunsuz
- Lead Free
- Operating Supply Voltage
- 30V
- Max Voltage Rating Dc
- 30V
- Lead Pitch
- 5.1mm
- Resistance Initial Ri Min
- 30mOhm
- Reach Svhc
- Unknown
- HTS Kodu
- 8533.40.80.70
- Kılıf / Paket
- Radial, Disc
- Montaj Tipi
- Through Hole
- Power Dissipation
- 1W
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
