Specifications
- Yayın Yılı
- 2010
- Trip Current
- 2.7A
- JESD-609 Kodu
- e3
- ECCN Kodu
- EAR99
- Boyut / Ölçü
- 0.350Lx0.118W 8.90mmx3.00mm
- Onay Kuruluşu
- cURus, TUV
- Tip
- Polymeric
- Resistance Post Trip R1 Max
- 130mOhm
- Terminal
- Radial
- Lead Spacing
- 0.201 5.10mm
- Packing Method
- AMMO PACK
- Parça Durumu
- Active
- Time To Trip
- 7.3s
- Current Hold Ih Max
- 1.35A
- Additional Feature
- FLAME PROOF, MINIMUM RESISTANCE IS 0.04 OHMS
- Çalışma Sıcaklığı
- -40°C~85°C
- Seri
- POLY-FUSE®, 30R
- Terminal Sayısı
- 2
- Akım Değeri
- 40A
- Terminal Kaplaması
- Matte Tin (Sn)
- Maks. Oturma Yüksekliği
- 0.532 13.50mm
- Direnç
- 130mOhm
- RoHS Durumu
- ROHS3 Compliant
- Thickness
- 3.05mm
- Yüzey Montaj
- NO
- Thermistor Application
- OVERCURRENT PROTECTION
- Max Voltage Rating Dc
- 30V
- Kurşunsuz
- Lead Free
- Fabrika Tedarik Süresi
- 12 Weeks
- Hold Current
- 1.35A
- Lead Pitch
- 5.1mm
- Resistance Initial Ri Min
- 40mOhm
- Montaj Tipi
- Through Hole
- Kılıf / Paket
- Radial, Disc
- Power Dissipation
- 800mW
- HTS Kodu
- 8533.40.80.70
- Ambalaj
- Tape & Box (TB)
- Max Current Rating
- 40A
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
