Volume pricing
- 1+ pcs$0.63
- 10+ pcs$0.60
- 100+ pcs$0.56
- 500+ pcs$0.53
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Kaplaması
- Matte Tin (Sn)
- Voltage Rated Dc
- 30V
- Maks. Oturma Yüksekliği
- 0.480 12.20mm
- Yüzey Montaj
- NO
- Thickness
- 3.05mm
- RoHS Durumu
- ROHS3 Compliant
- Direnç
- 220mOhm
- Thermistor Application
- OVERCURRENT PROTECTION
- Max Voltage Rating Dc
- 30V
- Nominal Gerilim
- 30V
- Operating Supply Voltage
- 30V
- Hold Current
- 900mA
- Fabrika Tedarik Süresi
- 12 Weeks
- Kurşunsuz
- Lead Free
- Lead Pitch
- 5.1mm
- Reach Svhc
- Unknown
- Resistance Initial Ri Min
- 70mOhm
- Power Dissipation
- 600mW
- Montaj Tipi
- Through Hole
- Kılıf / Paket
- Radial, Disc
- Max Current Rating
- 40A
- Ambalaj
- Tape & Box (TB)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Yükseklik
- 12.2mm
- Terminal Shape
- WIRE
- Trip Current
- 1.8A
- Yayın Yılı
- 2010
- JESD-609 Kodu
- e3
- Onay Kuruluşu
- cURus, TUV
- Boyut / Ölçü
- 0.291Lx0.118W 7.40mmx3.00mm
- Resistance Post Trip R1 Max
- 220mOhm
- Terminal
- Radial
- Lead Spacing
- 0.201 5.10mm
- Tip
- Polymeric
- Parça Durumu
- Active
- Packing Method
- AMMO PACK
- Time To Trip
- 5.9s
- Current Hold Ih Max
- 900mA
- Additional Feature
- FLAME PROOF, MINIMUM RESISTANCE IS 0.07 OHMS
