Volume pricing
- 1+ pcs$0.05
- 10+ pcs$0.05
- 100+ pcs$0.05
- 500+ pcs$0.05
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- HTS Kodu
- 8533.40.80.70
- Power Dissipation
- 800mW
- Boyut / Ölçü
- 0.179Lx0.128W 4.55mmx3.24mm
- Maks. Kalınlık
- 0.039 1.00mm
- Onay Kuruluşu
- cURus, TUV
- Çalışma Sıcaklığı
- -40°C~85°C
- Kurşunsuz
- Lead Free
- Current Hold Ih Max
- 2.6A
- Max Voltage Rating Dc
- 8V
- Terminal Placement
- DUAL ENDED
- Operating Supply Voltage
- 8V
- Direnç
- 47mOhm
- Case Code Metric
- 4532
- Resistance Post Trip R1 Max
- 47mOhm
- RoHS Durumu
- ROHS3 Compliant
- Current Trip It
- 5.2A
- Fabrika Tedarik Süresi
- 12 Weeks
- ECCN Kodu
- EAR99
- Akım Değeri
- 100A
- Resistance Initial Ri Min
- 15mOhm
- Working Voltage
- 6V
- Kılıf / Paket
- 1812 (4532 Metric), Concave
- Time To Trip
- 2.5s
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Power Dissipation
- 800mW
- Max Current Rating
- 100A
- Tip
- Polymeric
- Seri
- POLY-FUSE®, 1812L
- Yayın Yılı
- 2006
- Ambalaj
- Tape & Reel (TR)
- Additional Feature
- RESISTANCE MIN IS 0.015 OHMS
- Terminal Sayısı
- 2
- Terminal
- SMD/SMT
- Yüzey Montaj
- YES
- Reach Svhc
- Unknown
- JESD-609 Kodu
- e3
- Montaj Tipi
- Surface Mount
- Parça Durumu
- Active
- Voltage Rated Dc
- 8V
- Trip Current
- 5A
